Spec

• Operating temperature range: R.T. + 5 °C to Boiling temperature
• Temperature Adjustment Precision: ± 3 °C at Liquid Temperature 70 °C
• Temperature distribution accuracy: ±, 5 °C at liquid temperature, 70 °C
• Temperature rise time: about 35 minutes. R.T. → Boiling temperature
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Liquid expansion type
• Heater: SUS316L Pipe Heater
• Heater capacity: 1.4 kW
• Inner tank: SUS304
• Safety device: Overheat protection device, overcurrent/earth leakage breaker
• tank inner size: W 830 mm x D 150 mm x H 100 mm (H 45 mm)
• external dimensions : W 900 mm x D 290 mm x H 210 mm
• tank inner capacity (when full of water): about 12 L
• Number of Lid Holes: 1 Row 6 pieces
• Effective Diameter: Large φ 115 mm, Medium φ 85 mm, Small φ 55 mm
• power supply (50Hz/60Hz): AC100V 14 A
• Required power supply Equipment: AC100V 20 A
• Mass: about 14 kg
• Accessories: Stainless Steel Lid 1 piece, Ring Lid Type 1, shelf board 1 piece, strut 2 pieces, clamp Type 1, Horizontal Bar 1 piece, Clamp Type 1, Thermometer (0 °C, to 100 °C), 1 piece
