Spec

• Measurement category…CAT Ⅳ(600V)
• AC Current …60/600/3000A
• Frequency …40 to 1000Hz
• Display …Liquid Crystal 、6000Count
• Range Change …Auto
• Max. Measurement Core Dia. …Max. Dia 120mm
• Sampling …3 times/Second
• Use Temperature And Humidity …0 to +40℃、80%RH Or Less (However, there is no condensation)
• Preservation Temperature And Humidity …-10 to +60℃、80%RH Or Less (However, there is no condensation. Not included battery)
• Size …178(W) x 30(D) x 324(H)mm (Test Lead Except )
• Weight …About 188g(Including Batteries )
• Power Supply …AAA Battery x 3 Pcs (included)
• Battery Life …About 70 Hours (In using Alkalinity Battery)
• Proofreading …Possible
• With Storage Case
• True Effective Value Measurement Possible
• Function …Data Hold 、Auto Power Off 、 Backlight 、With Led Light 、 True Effective Value
• By the cable that can change the shape freely, measurement is easily possible even at narrow places.
• By the measurement method of real effective value, display of the effective value is possible, even for the waveforms other than the sine wave.
• Current and frequency can be displayed on the LCD screen simultaneously.
• The hand grip style which can be grasped firmly is adopted.
• Equipped with a backlight for LCD so that the measured value can be confirmed even at dark places
• Equipped with the LED light so that the measuring object can be confirmed even at dark places
• It is possible to confirm the measured values carefully, by the data holding function.
