Spec

• …


• The number of pixels …160 x 120 Pixels
• Temperature Resolution (NETD)…100 mK
• View angle (FOV) / Minimum Focal Distance …31° x 23° / to50cm
• Space Resolution (IFOV)…3.4 mrad
• SuperResolution…320 x 240 Pixels / 2.1 mrad
• Frame ・The rate …9 Hz
• Focus …Fixed Focus
• Measurement Wavelength …7.5 - 14 μm
• …


• The number of pixels / Minimum Focal Distance …Min. 3.1 Mega Pixels / 50cm
• …
• DisplayScreen …8.9 cm (3.5"") LCD、 QVGA (320 x 240 Pixels )
• Change Image …・Heat Picture ・Visible Picture
• Interface…・Wireless LAN ・USB 2.0 micro B
• Color Palette …4 Variety : ・Iron ・RainbowHC ・Cold-Warm ・Gray
• …


• Temperature Measurement Range …-30 to 650 °C
• Accuracy …・-30 to -21°C: ± 3 °C ・-20 to +650°C: ±2 °C Or Big Measurement ± 2％
• Emissivity /Reflection Temperature Correction …0.01 to 1.00 / Manual Input
• ε-Assist…Emissivity Automatic Recognizing and Reflection Temperature (RTC)Automatic Measure
• Measurement Function …・Single-Point Measurement ・Cold Spot ・Hot Spot ・Difference Temperature Display ・The scale ・Assist ・IFOV Indicator
• …


• Digital ・camera …Possible
• Full Screen Mode …Possible
• File Type ….jpg
• Video Streaming…・USB Connection ・Possible by exclusive application at the time of wireless LAN connection
• …


• File Type・.jpg ・.bmt ・Exported with an option by the next file format : (.bmt, .jpg, .png, .csv, .xls)
• Memory Volume …Built-In Memory Volume 2.8 GB、 About 2000 Picture (SuperResolution Nothing )
• …
• Battery ・Type …LithiumIon Rechargeable battery 2500 mAh / 3.7 V
• Battery Working Time …About 4 Hour (Ambient Temperature At the time of 20 ℃)
• Charging Way …Using AC Adapter in a loading state in the Thermography
• Recharge Time …About 5 hours with AC Adapter、 About 8 hours in the USB interface of the PC
• …


• Operation Temperature …-15 to 50 ℃
• Storage Temperature …-30 to 60 ℃
• Humidity …20 to 80 ％ RH(No freezing )
• …


• Outside Type size …96 x95 x 219 mm
• Weight …510 g (Included Battery)
• Housing …PC/ABS
• Keeping Class (IEC 60529)…IP 54
• Vibratility resistant (IEC 60068-2-6)…2 G
• Set Details …Body (Wireless LAN Module Adapted )、 USB Cable 、AC Adapter 、 Battery Software for analysis 、 ε-Marker x 3Sheet 、Exclusive Use Case "
