Spec

• Operating temperature range: 70 °C to 350 °C (plate surface temperature)
• Temperature Adjustment Accuracy: ± 10 °C
• Temperature rise time: about 60 minutes, from R.T. to 350 °C
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Thermocouple ON/OFF Control
• Temperature sensor: K class thermocouple
• Heater: Mica Plate Heater
• Heater capacity: 1.35 kW
• Plate material: Aluminum (Ceramic Coating)
• Insulation: Ceramic fibre, Rockwool
• Safety device: Overcurrent breaker
• Plate Dimensions: W 350 mm x D 250 mm
• external dimensions : W 385 mm x D 320 mm x H 200
• power supply (50Hz/60Hz): AC100V 13.5 A
• Required power supply Equipment: AC100V 40 A
• Mass: about 17 kg
