Spec

• Operating temperature range: 20 °C, to 100 °C
• Temperature Adjustment Accuracy: ± 0.3 °C
• Temperature distribution precision: ± 0.5 °C at 20 °C to 60 °C ± 1.0 °C at 60.1 °C to 100 °C
• Temperature rise time: 75 minutes or less 20 °C → 100 °C
• Humidity Range: 40 %RH, to, 95 %RH
• Humidity Adjustment Precision: ± 3, %RH
• Humidity Distribution Precision: ± 3 %RH
• Ambient operating temperature: 5 °C, to 35 °C
• Temperature and humidity controller: Microcomputer PID control (HTC-SII system)
• Operation type : Fixed value Operation
• Temperature and humidity sensor: platinum resistance thermometer Pt 100 Ω (dry/wet bulb detection system)
• Heating Heater: Stainless Steel Sheath Heater
• Humidification Heater: Stainless Steel Sheath Heater
• dehumidifier system: TEC (air-cooled)
• Blower Fan: Propeller Fan (Aluminum)
• Interior: SUS304
• Insulation: Rigid polyurethane board for high temperatures
• Door: Double Door (Inner Door tempered glass) Silicone Rubber Packing
• Safety device: Self-diagnostic function (Overheating, Temperature/Humidity Sensor Disconnection, Empty Heating), indep***ent overheat protection device, control circuit overload protection device, blower overload protection device, Peltier element protection device, water interruption alarm, overcurrent/leakage breaker
• External input/output signal terminals: temperature (DC1V, to 5V), humidity (DC1V, to 5V), alarm output (contact signal)
• inner dimension: W 300 mm x D 250 mm x H 300 mm (H 250 mm)
• external dimensions : W 560 mm x D 535 mm x H 550 mm
• Internal Volume: Approximately 22.5 L
• Shelf Bracket pitch: 30 mm
• Measuring Hole: φ 40 mm Left Side
• power supply (50Hz/60Hz): AC100V 9A
• Required power supply Equipment: AC100V 15 A
• Mass: about 50 kg
• Accessories: shelf board 2 pieces, Shelf Bracket 4 pieces, Gauze for Humidity Sensor 2 pieces, Level 1 piece, Fixed metal bracket 4 pieces (Mounting Screw 8 pieces), Measurement Hole rubber plug 1 piece, Spanner 1 piece
