Spec

• Operating temperature range: -40 °C, to 100 °C
• Temperature Adjustment Precision: ± 0.3 °C at 20 °C
• Temperature distribution precision: ± 0.75 °C at 20 °C
• Temperature rise time: 40 minutes or less R.T. → 100 °C
• Temperature fall time: 60 minutes or less R.T. → -40 °C (50Hz)
• Humidity Range: 20 %RH, to, 95 %RH
• Humidity Adjustment Precision: ± 2 %RH
• Humidity Distribution Precision: ± 3 %RH
• Ambient operating temperature: 5 °C, to 35 °C
• Temperature and humidity controller: Microcomputer PID control (HTC-PC system)
• Operation type: Constant value Operation, program Operation (100 patterns, 1,000 steps)
• Temperature and humidity sensor: platinum resistance thermometer Pt 100 Ω (dry/wet bulb detection system)
• Heating Heater: Stainless Steel Sheath Heater (with Fin)
• Humidification Heater: Stainless Steel Sheath Heater
• Refrigerator: 600 W + 750 W + 2,000 W R 404 A
• Blower Fan: Sirocco Fan (Aluminum)
• Interior: SUS304
• Insulation: Rigid polyurethane board for high temperatures
• Door: Double Door (Inner Door tempered glass) Silicone Rubber Packing * Can be Changed to Fluororubber
• Safety device: Self-diagnosis function (Overheating, Temperature/Humidity Sensor Disconnection, Empty Burning, Refrigerator/blower Overload), indep***ent overheat prevention device, control circuit overload protection f***, refrigerator high voltage switch, water cut off alarm, automatic drain function, overcurrent and leakage breaker
• External input/output signal terminal: Output: Temperature (DC1 V, to 5 V), Humidity (DC1 V, to 5 V), Alarm output (Contact signal), Input/Output: RS -232 C
• inner dimension : W 600 mm x D 800 mm x H 850 mm
• external dimensions : W 1,100 mm x D 1,265 mm x H 1,790 mm
• Internal Volume: Approximately 408 L
• Shelf Bracket pitch: 50 mm
• power supply (50Hz/60Hz): 200 VAC 3-phase 25 A
• Required power supply Equipment: 200 VAC, 3 Phase, 40 A
• Mass: about 350 kg
• Accessories: shelf board 2 pieces, Shelf Bracket 4 pieces, Vinyl Hose for Drainage 2 pieces, Horseband 2 pieces, Gauze for Humidity Sensor 2 pieces, Level 1 piece, Driver 1 piece, Fixed metal bracket 4 pieces for Floor (Mounting Screw 8 pieces)
