Spec

• Convection system: can heating
• Operating temperature adjustment range: 40 ~ 240 degrees Celsius
• Temperature control accuracy: +/- 1.5 degrees C (240 degrees C setting)
• Time to reach temperature: about 80 minutes
• Reached vacuum: 133 Pa (1 Torr)
• Timer time range: 1 minute to 99 hours 59 minutes
• Temperature control/sensor: Microcomputer P.I.D control with auto-tuning function, SSR output/K thermocouple
• Timer program function: 1-step repetition, 2-step repetition
• Safety functions: Door opening, setting error, upper/lower temperature, sensor failure, heater break, SSR failure, power failure, ground fault/overcurrent breaker, indep***ent overrise detector
• Heater: 1.2 kW
• Vacuum gauge: Bourdon tube type
• Interior dimensions (width x depth x height): 300 x 300 x 300 mm
• Storage capacity (L): 27
• Shelf Board Load Capacity, Material: Equal Distribution Max. Load Capacity: 15 kg/Sheet, NSSC 180
• Shelf Plates Attached: 2 (Mountable Plates: 4)
• Number of shelf pitch stages: 71 mm, 4 (fixed)
• Observation Window (mm): 250 x 250
• Door inner surface: Tempered glass 12 mm thick
• Exhaust Gas Part Material/Door Packing: Silicon, Inside: SUS 304, SUS 430 J 1 L, Glass, Piping: Copper, Brass, Fluororubber, Aluminum
• Connection diameter: suction nozzle, outer diameter 22 mm hose mouth, purge nozzle, outer diameter 22 mm hose mouth (inner screw PF 1/4, inner G 1/4)
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions (width x depth x height): 505 (523) x 545 (570) x 760 mm/* Dimensions in () include projections.
• Mass (kg): about 60
• Power input/rated power: 12.5 A 1.25 kVA AC 100 V 50/60 Hz
• Power cord: 2.9 m
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage, 50 Hz and no load.
• *Temperature Reach Time is the value at the temperature of the can body surface under reduced pressure.
• *A vacuum pump is required for ***.
• Code: 263810
• *Shipping, carrying-in, installation and assembly costs are required separately. Please inquire.
