Spec

• Natural convection system
• Interior dimensions (width x depth x height): 450 x 450 x 450 mm
• Storage capacity (L): 91
• Temperature adjustment range: room temperature + 10 ~ 270 degrees C
• Temperature control accuracy: less than +/- 1 degree C
• Temperature distribution: Spatial temperature deviation 11 degrees C/temperature gradient 16 degrees C
• Temperature reach time: 110 minutes
• Temperature control, setting and display: Microcomputer P.I.D control SSR output, sheet key input, digital display
• Timer program function: Auto start, Auto stop, Auto start stop, 1 step/2 step mode
• Safety features: Door open, upper/lower limit alarm, sensor failure, heater break, SSR failure, ground fault/overcurrent breaker, variable indep***ent overrise prevention
• Heater: Stainless sheath heater　　1.0kW
• Shelf Board Load Capacity, Material: Uniform Distribution Max. 15 kg/Sheet, SUS 304
• Shelf Plates Included: 2 (1 fixed at bottom)
• Shelf Pitch/Number of Racks: 30 mm/11 Racks
• Observation Window: 250 W x 280 H (triple glazing)
• Interior and Door Packing Materials: NSSC 180, Silicon
• Vent/Cable holes: top 2 places phi 28 mm, right 1 place phi 37 mm
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions (width x depth x height): 550 (561) x 590 (625) x 815 (826) mm/* Dimensions in () include projections.
• Mass (kg): about 56
• Power input/rated power: 11 A, 1.1 kVA/100 VAC 50/60 Hz
• Power cord: 2m
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage, 50 Hz, no load, exhaust port and closed cable holes. *Performance notation for temperature distribution conforms to JIS C 60068 -3 -5 JTM K 07 -2007 (Performance test method and performance display method of temperature test tank, Japan Testing Machine Industry Association).
• Code: 252250
