4-2072-01 Vacuum Cooling Plate PRD-1
Product Description
Product Model: 4-2072-01Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 4-2072-01
Product Brand: AS ONE Corporation
Features
- Vacuum specification of cooling and heating plate using Peltier element, can be ***d for cooling and heating experiment under reduced pressure and vacuum drying.
- By vacuuming the inside of the transparent acrylic cover on the plate, it is possible to conduct experiments while checking the state of the inside when the pressure is reduced.
- It comes with a patin lock for 4 pieces, and can replace gas after decompression.
- A low-temperature vacuum dryer for easy observation!
Spec
- top board size (mm) : 150 x 150
- Temperature Band (degrees C): 0 to 60
- material: Body/Steel, Cover/Acrylic
- external dimension : Body/170 x 170 x 170 mm , Control Box/150 x 195 x 95 mm
- Allowable Vacuum: -0.09 MPa
- outer diameter: Φ6 One-touch Valve for Tube x 2
- power supply: AC100V 50/60 Hz
- Weight: Body/2.5 kg, Control Box/2.5 kg
- Power Consumption: about 100 W
