62-6178-58 Polybent (50 mm PTFE 0.2 μm) 1 Pack (10 pcs) 6713-1650
Product Description
Product Model: 62-6178-58Product Brand: Cytiva (Whatman […]
Contact Us
Product Details
Product Model: 62-6178-58
Product Brand: Cytiva (Whatman)
Features
- Passed sterilization grade HIMA challenge test
- The catch count of Brevundimonas diminuta was more than 10^7 CFU/cm2, which complies with ASTM standard F838-83.
- This ability to retain microorganisms correlates with the 100% integrity test (evaluated in liquid form) in the manufacturing process (100% integrity test is only performed in capsule form).
- An integrated filter developed for sterile venting. Consisting of only one standardised material (PTFE membrane and polypropylene housing) helps simplify the approval process.
- Hydrophobic PTFE membrane with a pore size of 0.2 μm
- Steam sterilization by autoclave is possible up to 50 times, and ethylene oxide gas is also supported.
- Water breakthrough (WBT) test or bubble point test possible
- Manufactured in a clean room facility
- Both Directions Enabled
- Note)Only for test and research purposes.
Spec
- Housing: Polypropylene
- Filter Material: PTFE (Polytetrafluoroethylene)
- Pore size: 0.2 μm
- vents: inlet side
- Support System: Polypropylene
- bonding methods: heat welding
- Voltage: 0.2 MPa (29psi) (if forward)
- Water Test: 0.2 MPa (29psi)/15 sec.
- Direction of filtration: reverse filtration is possible only at low pressure
- Sterilization: Autoclavable at 121°C for 20 minutes (maximum temperature 132°C). It is possible to autoclave repeatedly, but use at the user's responsibility to avoid cross contamination. Perform the integrity test after autoclaving. Sterilization with ethylene oxide gas is possible.
- No pyrogens: No response in the total LAL test
- Effective Filtration Area: 16 cm2
- Pore Diameter (μm): 0.2
- Type of housing: 50 mm disc type
- Connection Inlet: SB
- Connection outlet: SB
- SB= Stepped Hose Port: Can be connected to 6~10 mm (1/4”-3/8”) tubing
