toner
1-2175-21 Digital Multimeter 1000 Ω U1241C
model:
1-2175-21
category:
toner
Product Description
Product Model: 1-2175-21 Features Data can be recorded […]
Contact Us
Product Details
Product Model: 1-2175-21
Features
- Data can be recorded on device internal memory, or it can be done by special software after connecting device to PC via cable.
- Equipped with V-sense function（non-contact method for detecting voltage） to give added protection of not having to touch any live wires.
- If voltage is detected, alarm sounds and LED indicator flashes to notify ***r.
- Built-in LED flashlight can be turned on single-handedly to illuminate the work.
Spec
- Model number: U1241C
- Specification: Body
- Display resolution: 10,000 counts resolution, dual display
- DC voltage basic accuracy: 0.0009
- Measurement range: DC voltage, AC voltage/100mV - 1000V, DC current, AC current/1000μA - 10 A, Resistance/1000Ω (U1241C), 100Ω - 100MΩ (U1242C), Frequency/100Hz - 10MHz, Capacitance/1000nF - 10mF, Temperature (K class thermocouple)/-200℃ - 1372℃
- Power supply: AAA alkaline battery x 4 (included for test)
- Safety standards, regulatory compliance: CATIII 1000V/CATIV 600V, EN/IEC 61010-2-030: 2010, EN/IEC 61010-1: 2010
- Size: 198 x 96 x 57mm
- Weight: 545g
- Dustproof, waterproof: IP-67
- Accessories: Test probe, Lead, Calibration certificate
