61-9660-20-90 【Global Model】Forced Convection Oven (High Temp.)  DN411H DN411H
laboratoryinstruments

61-9660-20-90 【Global Model】Forced Convection Oven (High Temp.)  DN411H DN411H

model: 61-9660-20-90
brand: Yamato Scientific Co., Ltd.

Product Description

Product Model: 61-9660-20-90Product Brand: Yamato Scien […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 61-9660-20-90
Product Brand: Yamato Scientific Co., Ltd.

Features

  • Operability/Function
  • Heat resistance testing and heat treatment at high temperatures up to 360°C can be performed easily.
  • The operating temperature range is wide and high precision temperature control is possible.
  • In addition to various operation modes including program operation, various support functions such as calibration offset function, power failure recovery mode selection, user setting information storage and ringing function are provided as standard.
  • Program operation of up to 99 steps, 99 patterns and repetition is possible.
  • Equipped with power supply/operation time integration function.
  • With cable holes, data can be easily collected from internal sample equipment.
  • Safety and maintenance: We have further enhanced safety features such as a self-diagnosis function and a digital setting independent excessive rise prevention device. When the door is opened during operation, the door switch operates to turn off the fan and heater.

Spec

  • Circulation method: Forced air circulation
  • Operating temp. range: RT+15~360℃
  • Temp. adjustment accuracy: ±0.2℃ (at 360℃) JTM K05
  • Temp. fluctuation: 1.2℃(at 360℃) JIS
  • Temp. distribution accuracy: ±3.0℃(at 360℃) JTM K05
  • Temp. gradient: 12℃(at 360℃) JIS
  • Max. temp. reaching time: Approx. 60 min
  • Internal dimentions(WxDxH): 470 x 450 x 450mm
  • External dimentions(WxDxH): 640 x 695 x 915mm
  • Internal capacity: Approx. 95L
  • No. of steps/pitch: 12 steps/30mm
  • Shelf load capacity : Approx. 30 kg/pc
  • Power supply: AC220V 50/60Hz single phase 15A (plug is not included)
  • Weight: Approx. 90kg
  • Accessories: Stainless shelf x 2, Shelf bracket x 4, Manual
