3-9238-11 Soldering tip thermometer FG100B-83
Product Description
Product Model: 3-9238-11Product Brand: HAKKO Features E […]
Contact Us
Product Details
Product Model: 3-9238-11
Product Brand: HAKKO
Features
- Equipped with an AUTO HOLD function, measurement is automatically terminated when the trowel tip temperature is stabilized to minimize the measurement difference by the operator.
- With the MAX HOLD function plate, the maximum value of the measured tip temperature is always displayed and can be used for quality control of parts and boards.
- With a temperature measurement counting function, the number of times the trowel tip temperature is measured is automatically counted, and can be used for sensor replacement timing and process control.
Spec
- Size (mm): 68 × 38 × 140
- Main unit Weight (g): 125
- temperature measuring range: 0 to 700 ° C
- Temperature resolution: 1 ° C
- Temperature Sensor: K (CA) thermocouple (10 pieces Attached)
- Temperature Measurement Tolerance: 300 to 600 ° C/± 3 ° C, Other Range/± 5 ° C
- power supply : 9V Alkaline battery (test attachment)
- With auto shut-off function
- *AUTOHOLD and MAX HOLD functions cannot be used at the same time.
