63-4641-90 RS PRO Insulated Male Crimp Bullet Connector, 2.5mm² to 6mm², 12AWG to 10AWG, 5mm Bullet diameter, Yellow 534-935
Product Description
Product Model: 63-4641-90Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-4641-90
Product Brand: RS PRO
Features
- RS Pro Insulated Double Crimped Oz Barrett Terminal
- RS Pro Insulated Male Double Crimped Barrett Terminal Series has a brass sleeve barrel insulated with flared vinyl. These insulated male crimped valet wire connectors are color-coded for *** with different wire sizes. All models boast high reliability and excellent quality.
- Wire Size Red, 0.5-1.5 mm2 Blue, 1.5-2.5 mm2 Yellow, 2.5-6.5 mm2
Spec
- Insulation:Insulated
- Insulation Material:Nylon
- Overall Length:25mm
- Minimum Wire Size mm²:2.5mm²
- Maximum Wire Size mm²:6mm²
- Minimum Wire Size AWG:12AWG
- Maximum Wire Size AWG:10AWG
- Bullet Diameter:5mm
- Shrouded/Unshrouded:Unshrouded
- Contact Plating:Tin
- Contact Material:Copper
- CODE No.:534-935
