65-9009-68 ［Discontinued］High Coupler Hose Size 3/8 Brass 107 g Socket 30SHBRASSFKM
Product Description
Product Model: 65-9009-68Product Brand: NITTO KOHKI CO. […]
Contact Us
Product Details
Product Model: 65-9009-68
Product Brand: NITTO KOHKI CO., LTD.
Features
- For low pressure.
- "Coupler" with excellent versatility, from air piping in factories to hose connections for air tools.
- Brass is suitable for water. However, be aware that the fluid on the plug side will flow out during separation.
- A wide range of body materials, sizes and mounting shapes have been standardized to meet a wide range of pneumatic applications.
- Compatibility: Model 10, Model 17, Model 20, Model 30, Model 40 can connect the socket and plug regardless of the mounting shape. Can be connected to products of the "High Coupler" series and "Nat Coupler" series.
Spec
- Opposing Hose Size: 3/8
- Body Material: Brass
- Mass (g): 107
- L(mm):76.5
- ΦD(mm):25.4
- A(mm):34
- ΦT(mm):11.3
- ΦB(mm):7.5
- Valve Structure: One Way Opening/Closing Type
- Applied fluids: Air, Water
- Maximum Working Pressure (MPa{kgf/cm2}): 1.0{10}
- Pressure Capacity (MPa{kgf/cm2}): 1.5{15}
- Seal Material: Fluororubber
- display symbols: FKM
- Operating Temperature Range (°C): -20 to +180
- Remarks: Standard Material
- Mounting Shape: Hose Nipple
- Type: Socket
