65-9007-08 ［Discontinued］TSP Coupler Hose Size 3/8 Stainless Steel 96 g 3TSHSUSEPDM
Product Description
Product Model: 65-9007-08Product Brand: NITTO KOHKI CO. […]
Contact Us
Product Details
Product Model: 65-9007-08
Product Brand: NITTO KOHKI CO., LTD.
Features
- For medium pressure.
- Since it is a valveless structure, pressure loss is greatly reduced and large flow rate is obtained.
- Suitable for fluids with high viscosity (such as grease).
- Various body materials, sizes and mounting shapes have been standardized to meet a wide range of applications and conditions.
- Compatibility: The socket and plug can be connected regardless of the mounting configuration, as long as the initial letters of the product type are the same.
Spec
- Opposing Hose Size: 3/8
- Body Material: Stainless Steel
- Mass (g): 96
- L(mm):62
- ΦD(mm):28
- A(mm):32
- ΦT(mm):11
- ΦB(mm):7
- Valve Structure: Double Road Open Type
- Maximum Working Pressure (MPa{kgf/cm2}): 7.5{76}
- Pressure Capacity (MPa{kgf/cm2}): 10.0{102}
- Seal Material: Ethylene Propylene Rubber
- display symbols: EPDM
- Operating Temperature Range (°C): -40 to +150
- Remarks: Standard Material
- Mounting Shape: Hose Nipple
- Type: Socket
