Spec

• Correspondence electrophoretic plate: for M type scratchbuild gel (MAB-01/MB-00)
• Size 120mm (W) x 102mm (L), Use MAB-01, MB-00, TOTAL 7mm thickness
• For P type ready-made gel (e-PAGEL/PAGEL)
• Size 120mm (W) x 100mm (L), e-PAGEL, PAGEL, TOTAL 5mm thickness
• Gel size: 90mm (W) x 80 - 83mm (H) x 1mm (D)
• Number of simultaneous electrophoresis gels: 1 sheet or 2 sheets
• Plate installing system: Katitte seal system
• Plate constant temperature system: Double-sided constant temperature by lower buffer solution.
• Buffer solution capacity: Top 80mL bottom 420mL
• Safety measures: Lead wire-integrated safety cover
• Material: Polycarbonate, Silicone
• Electrophoresis tank polarity: Automatic polar switching function (upper tank regardless of power connection direction: Cathode, Lower tank: Anode)
• Body dimensions, mass: 94mm (D) x 164mm (W) x 154mm (H) 0.65kg (excluding accessories)
• Standard components: Body (M specification) (with lead wires), Dummy plate 7mm thickness, Instruction manual:
