61-3613-30 Oil Diffusion Pump Baffle Set SDP-3
Product Description
Product Model: 61-3613-30Product Brand: SATO VAC INC. F […]
Contact Us
Product Details
Product Model: 61-3613-30
Product Brand: SATO VAC INC.
Features
- The vacuum pump ***d when high vacuum is required can provide 10-5 Pa at a low cost.
- It is evacuated to the high vacuum region by a supersonic jet jet generated by the jet of heated diffusion oil from the nozzle.
- It cannot be operated indep***ently, but is ***d in combination with an oil rotary vacuum pump as a back pump.
- For products that are combined into an exhaust set, refer to the High Vacuum Exhaust Device in the Vacuum Device.
Spec
- Exhaust speed (without baffle/with baffle): 16.8/9.0mL/min
- Achieving pressure: 0.00001Pa
- Oil reverse flow rate (without baffle/with water-cooled baffle): x 10-2/x 10-4mg/cm2min
- Oil amount: 100mL
- Power supply: 100V
- Power: 0.5W
- Starting hour: 20min
- Water amount: 1.0L/min
- Critical backing pressure: 20Pa
- Mass: 6kg
- Model number: SDP-3
*This product might require extra fees.
