Spec

• Rated 300 V -10 A (domestic)
• Insulation resistance DC 500 V, 100 Momega or more
• Withstand voltage: 2000 V AC (1 minute)
• With check holes
• Main Insulation Material (Body) Nylon 66 (UL 94 V-0)
• Main Insulation Material (Button) P.P.E. (UL 94 V-0)
• Rated Current Compatible Wire Single Wire: 1.2 mm, Stranded Wire: 1.25 mm 2, Strand Wire Diameter: 0.18 mm or more
• Usable wire range: single wire: phi 0.4 mm to phi 1.2 mm (AWG 16 to AWG 26), twisted wire: 0.2 mm 2 ~ 1.25 mm 2 (AWG 16 to AWG 24), wire diameter phi 0.18 mm or more, ferrule: 0.25 mm 2 ~ 0.5 mm 2 (AWG 20 to AWG 24)
• Terminal metal fittings PC terminal
• Standard stripping line length 9 ~ 10 mm
• Recomm***ed Compliant Tool Slotted Screwdriver (Shaft diameter phi 3 mm, blade width 2.6 mm)
