Features

• Description
• The Espressif ESP32-C3 is the next version of the popular ESP32 Bluetooth®and WiFi enabled module. This module features a single core, RISC-V-based processor with WiFi and Bluetooth LE 5.0 radios built into the SoC. The module features a PCB antenna and castellated plated pins for surface-mount soldering. This variation has 4 MB of on-board SPI flash and is the 85 °C temperature tolerant version.
• The 32-bit core RISC-V microcontroller features a maximum clock speed of 160 MHz. With 22 configurable GPIOs, 400 KB of internal RAM and low-power-mode support, it can facilitate many different ***-cases involving connected devices. The high-temperature support makes it ideal for industrial and lighting ***-cases as well. The module is supported through Espressif's open-source ESP-IDF making it easy to develop around.
• WiFi and Bluetooth LE 5.0 with long-range(LR)support **** building devices with great coverage and improved usability. ESP32-C3 continues to support Bluetooth LE SIG Mesh and Espressif WiFi Mesh. Furthermore, the solid RF performance of ESP32-C3 is sustained at a higher operating temperature.
• Security is now a main feature of the ESP32 line. The ESP32-C3 ensures that the availability of features, such as the RSA-3072-based secure boot and the AES-128-XTS-based flash encryption, can be ***d to build connected devices securely. The innovative digital signature peripheral and the HMAC peripheral provide a secure device identity for applications. Hardware acceleration support for cryptographic algorithms ensures good performance for the secure communication both in a local network and with the Cloud.
• Features
• MCU
• ESP32-C3 embedded, 32-bit RISC-V single-coreprocessor, up to 160 MHz
• 384 KB ROM
• 400 KB SRAM(16 KB for cache)
• 8 KB SRAM in RTC
• WiFi
• IEEE 802.11 b/g/n-compliant
• Center frequency range of operating channel:2412~2484 MHz
• Supports 20 MHz, 40 MHz bandwidth in 2.4 GHzband
• 1T1R mode with data rate up to 150 Mbps
• Wi-Fi Multimedia(WMM)
• TX/RX A-MPDU, TX/RX A-MSDU
• Immediate Block ACK
• Fragmentation and defragmentation
• Transmit opportunity(TXOP)
• Automatic Beacon monitoring(hardware TSF)
• 4×virtual Wi-Fi interfaces
• Simultaneous support for Infrastructure BSS inStation mode, SoftAP mode, Station + SoftAPmode, and promiscuous modeNote that when ESP32-C3 family scans in Stationmode, the SoftAP channel will change along withthe Station channel.
• Antenna diversity
• 802.11mc FTM
• Bluetooth
• Bluetooth LE:Bluetooth 5, Bluetooth mesh
• Speed:125 Kbps, 500 Kbps, 1 Mbps, 2 Mbps
• Advertising extensions
• Multiple advertisement sets
• Channel selection algorithm #2
• Hardware
• Interfaces:GPIO
• SPI
• UART
• I2C
• I2S
• remotecontrol peripheral
• LED PWM controller
• general DMA controller
• TWAI®controller(compatible withISO 11898-1)
• temperature sensor
• SAR ADC
• 40 MHz crystal oscillator
• 4 MB SPI flash
• Operating voltage/Power supply:3.0~3.6 VDC
• Operating ambient temperature:-40~85 °C(This is the 85 °C version module)
• Dimensions:(18.0×20.0×3.2)mm
