61-7664-78 ［Discontinued］Throttle Valve Stainless Steel (SUS316) Elbow R1/8 Clean Package SSNC6-01-C
Product Description
Product Model: 61-7664-78Product Brand: NIHON PISCO CO. […]
Contact Us
Product Details
Product Model: 61-7664-78
Product Brand: NIHON PISCO CO., LTD.
Features
- All metal parts are made of SUS316 which has excellent corrosion resistance.
- The seal ***s FKM with excellent chemical resistance.
- Ideal for fluids such as air, water, chemicals, and gas mixtures.
- The parts ***d are oil-proof and the material of the parts complies with the Food Sanitation Law.
- Clean with clean air and wrap in a clean room (ISO Class 6 equivalent).
Spec
- Fluid ***d: Air, Water, Other (*For chemicals and mixed gas, Conformity of our specifications may vary dep***ing on usage conditions. Please contact with the nearest office. )
- Used pressure range: Gas: 0 - 1.0MPa, Liquid: 0 - 0.3MPa (for *** of liquid, using insertion ring is recomm***ed.)
- Used vacuum pressure: -100kPa
- Operating temperature range: -15 to 120℃ (no freezing)
- RoHS supported
- Shape: Elbow
- Applicable tube size (outer diameter): φ6mm
- Applied screw size: (Taper screw for tube): R1/8
- Lubrication prohibited specification (conventional product)
- Package specification: Clean room packaging
- Seal tape specification: without seal tape
