Spec

• Applications: Heating/Cooling/Mixing
• Operating temperature range: min: R.T. minus 15 °C1), max: 100 °C
• temperature settings range: 1 to 100 °C
• Temperature Precision: ± 0.5 °C (20 to 45 °C)
• temperature uniformity: Max.　± 0.5 °C (20 to 45 °C) (in all positions on all smart blocks)
• Maximum heating rate: 7 °C/min2)
• Maximum cooling rate: 2.5 °C/min2) (R.T. to 100 °C)
• Mixing speed: 300 to 3000 rpm 2)
• Mixing stroke (diameter): 3 mm
• Time setting range: 15 seconds to 99.5 hours, continuous
• Compatible Accessories:
• Interchangeable Smart Blocks (Block Auto Recognition)
• Thermo Top (condens.protect ® technology)
• Lid
• SmartExt***er
• Program Features:
• Number of programs saved: 20
• Five program keys (configured, rewritable)
• Number of program steps: 4 steps
• Additional Features:
• 2 DMix-Control
• Anti-spill Technology
• short mixing
• interval mixing
• Time/Temperature Mode
• Pa*** Features
• USB Interface *
• power supply : 100 – 130 V ± 10% , 50 – 60Hz
• Power Consumption : 200 Watts (max.)
• Size (W x D x H): 20.6 x 30.4 x 13.6 cm
• Weight: 6.3 kg (main body only)
• *For maintenance only.
• 1)± 2 °C
• 2)Dep***s on the smart block ***d.
• Sold by block
• 100 V/50 - 60Hz
• Applications include: purification of plasmids/RNA/DNA, cDNA synthesis, enzymatic reactions (Restriction enzyme treatment, Proteinase K digestion, ligation, etc.), denaturation of DNA, RNA, and proteins, bacterial culture, and lysis at 100 °C
• Separate smart block required
