63-4634-46 RS PRO 3 Pole Din Socket, 1A, 100 V ac, Push Lock 491-184
Product Description
Product Model: 63-4634-46Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-4634-46
Product Brand: RS PRO
Features
- RS Pro Latched DIN Connector
- This latched DIN style connector, delivered by the trusted RS Pro brand, is similar to the shielded type, but has a built-in "push release" mechanism to prevent accidental release.
- This cable with a latched DIN connector latches only to the corresponding connector product.
- However, it engages with other connectors with the same pin configuration and DIN standard construction without latching.
Spec
- Number of Contacts:3
- G***er:Female
- Mounting Type:Cable Mount
- Connector Size:Standard
- Mating Type:Push Lock
- Body Orientation:Straight
- Current Rating:1A
- Voltage Rating:100 V ac
- Shielded/Unshielded:Shielded
- Series:YE-118XMS
- Housing Material:ABS
- Contact Plating:Silver
- CODE No.:491-184
