63-4630-23 Metal Oxide Varistor 510 V 15000 A 1 Bag (5 Pieces) B72220Q0321K101
Product Description
Product Model: 63-4630-23Product Brand: EPCOS Features […]
Contact Us
Product Details
Product Model: 63-4630-23
Product Brand: EPCOS
Features
- UL, CSA, CECC
- EnergetiQ Series-Q 14/Q20
- Minimum Component Height Maximum Load Capacity PSpice Model Coating: Epoxy Resin, UL94 V-0 Flame Retardant Terminals: Tin-plated Copper Wire
Spec
- Quantity: 1 Bag (5 Pieces)
- Varistor voltage: 510 V
- Maximum AC rated voltage: 320 V
- Maximum DC rated voltage: 420 V
- Limit voltage: 840 V
- Clamp current: 130 A
- Energy: 255 J
- Series: EnergetiQ
- Diameter: 22.5 mm
- Maximum surge current: 15000 A
- Capacitance: 780 pF
- Thickness: 6.3 mm
- Dimensions: 22.5 (Dia.) x 6.3 mm
- Lead Pitch: 10 mm
- RoHS compliance status: Compliance
- Securities Code: 468-156
