Spec

• Model number: S8FS-G03005C
• Output Voltage: 5 VDC
• Output Capacity: 30 W
• Input voltage: 100 ~ 240 V (shared 80 ~ 370 VDC)
• I/O connections: terminal strips
• Terminal Strip Type: Screw Terminal
• Efficiency: 81% type. (at 100 VAC input) 81% type. (at 200 VAC input) 81% type. (at 230 VAC input)
• Input voltage tolerance: 85 ~ 264 VAC (single-phase) 80 ~ 370 VDC
• Frequency: 50/60 Hz (47 ~ 450 Hz)
• Input current: 0.72 Atyp. (at 100 VAC input) 0.43 Atyp. (at 200 VAC input)
• Leak current: 0.5 mA or less (at 100 VAC input) 1 mA or less (at 200 VAC input)
• Inrush current: 14 Atyp. (at 25 C cold start) (at 100 V AC input) 28 Atyp. (at 25 C cold start) (at 200 V AC input)
• Output Current: 6 A
• Ripple noise voltage: 50 mV (p-p) or less at 100 ~ 240 VAC input
• Input variation: 0.5% or less
• Load Variation: 1% or Less
• Ambient temperature variation: below 0.05%/degree C
• Startup time: 1000 ms or less (at 100 VAC input) 1000 ms or less (at 200 VAC input)
• Output holding time: 11 mstyp. (at 100 VAC input) 60 mstyp. (at 200 VAC input)
• Overcurrent protection: yes, automatic return
• Overvoltage protection: Yes, power recovery
• Overheat protection: No
• Series operation: Yes (up to two units can be connected. External Diode Required)
• Parallel operation: no (However, backup operation is possible, external diodes are required)
• Output indicator light: Yes (color: green)
• Remote Sensing Remote Control: None
• Withstanding voltage: Between (input terminal bundle) and (output terminal bundle): AC 3 kV 1 min cutoff current 20 mA Between (input terminal bundle) and (PE): AC 2 kV 1 min cutoff current 20 mA Between (output terminal bundle) and (PE): AC 1 kV 1 min cutoff current 20 mA
• Insulation resistance: between (all output terminals) and (all input terminals/PE): 100 Momega or more 500 VDC
• Vibration resistance: 10 ~ 55 Hz, 4.5 G maximum, 0.375 mm single amplitude, 2 h each in 3 directions
• Elevation: 3000 m
• Operating ambient temperature: - 20 ~ 70 degrees C (0 ~ 90%)
• Thermal: - 25 ~ 75 C (0 ~ 90%)
• Expected life span: 10 years or more (Rated input, 50% load factor, ambient temperature + 40 C or less, in standard mounting condition)
• Cooling system: No cooling fan
• Mass: About 250 g
