63-7724-27 TRACOPOWER TES 2H 2W Isolated DC-DC Converter Surface Mount, Voltage in 4.5 → 5.5 V dc, Voltage out 5V dc TES 2-0511H
Product Description
Product Model: 63-7724-27Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-7724-27
Product Brand: TRACOPOWER
Features
- 3. Traco 1W SMD Single/Dual Output Unregulated Isolated DC-DC Converter - TES 2H Series. Small SMD package with standard footprint I/O isolation voltage 1500 Vdc Single and dual output models Input voltage 5, 12 and 24 Vdc High efficiency up to 80 % Operating temperature range –40 to +85°C High accuracy of pin co-planarity Qualified for lead free reflow solder process according to IPC/JEDEC J-STD-020D
Spec
- Quantity:1set(10pieces)
- Output Voltage : 5V dc
- Input Voltage Range : 4.5 → 5.5 V dc
- Input Voltage Nominal : 5 V dc
- Isolation Voltage : 1.5kV dc
- Power Rating : 2W
- Output Current : 400mA
- Mounting Type : Surface Mount
- Number of Outputs : 1
- Efficiency : 73%
- Package : DIP 8
- Minimum Temperature : -40°C
- Maximum Temperature : +85°C
- Series : TES 2H
- CODE No.:166-5305
