63-7718-92 Amphenol FCE17 Series Panel Mount, 9 Pin D-sub Connector Socket, Shell Size E Filtered D-Sub FCE17-E09SM-250
Product Description
Product Model: 63-7718-92Product Brand: Amphenol Featur […]
Contact Us
Product Details
Product Model: 63-7718-92
Product Brand: Amphenol
Features
- Amphenol Straight Solder Bucket Connectors. These Amphenol Filtered D-Sub FCE17 Series Straight Pin or Socket connectors are Panel mount with solder cup tails. Filter Capacitance of 470 pF, 820 pF, 1000 pF or 5600 pF are available indicated by a 1, 4, 5 and 9 in the Manufacturers Part Number i.e. FCE17-*****-*X** respectively Ø3 mm mounting holes with fixing centres of 25 mm, 33.3 mm, 47 mm or 63.5 mm for E09, A15, B25 and C37 sizes respectively Solder bucket termination with Matte Tin Plating accepts wire up to 20 awg Insulation Resistance 3000 MΩ Contact Resistance 15 mΩ
Spec
- Quantity:1bag(100pieces)
- Number of Contacts : 9
- G***er : Female
- D Connector Type : Filtered D-Sub
- D-Sub Shell Size : E
- Body Orientation : Straight
- Current Rating : 5A
- Contact Plating : Gold over Nickel
- Contact Material : Phosphor Bronze
- Length : 30.81mm
- Depth : 16.73mm
- CODE No.:170-2657
