63-7713-68 Preci-Dip 2.54mm 3-Way Spring Loaded Connector, -Row Male, Through Hole, 811-S1-003-10-014101 811-S1-003-10-014101
Product Description
Product Model: 63-7713-68Product Brand: Preci-Dip Featu […]
Contact Us
Product Details
Product Model: 63-7713-68
Product Brand: Preci-Dip
Features
- UL 94V-0. For counterpart SMD SIL Pad Connectors see stock number ; 702-0360 702-0360 (straight) or ; 702-5126 702-5126 (parallel) typical. 2.54 mm SIL Spring-Loaded Contacts, Through Hole. These Preci-dip SIL 813-S1 Series low resistance modular connectors have spring-loaded contacts (SLC) with through hole mounting into the PCB. The Height dimension gives the initial height of the spring-loaded contacts The plastic body height is 4 mm The plunger stroke length is 1.4 mm
Spec
- Quantity:1piece
- Number of Contacts : 3
- Pitch : 2.54mm
- Number of Rows : 1
- G***er : Male
- Mounting Type : Through Hole
- Body Orientation : Straight
- Height : 4mm
- Termination Method : Solder
- Current Rating : 3.5A
- Contact Plating : Gold
- Housing Material : Glass Fibre Reinforced PET
- Contact Material : Brass
- Voltage Rating : 100 V ac, 150 V dc
- CODE No.:701-9950
