Electronic/Electrical Parts and Controll Equipments
63-7673-50 Recom RI 2W Isolated DC-DC Converter Through Hole, Voltage in 21.6 → 26.4 V dc, Voltage out 12V dc RI-2412S
Product Description
Product Model: 63-7673-50Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-7673-50
Product Brand: Recom
Features
- Operating temperature is without derating. /P suffix de****s continuous short circuit protection. Recom 2W SIP Single Output Unregulated Isolated DC-DC Converter - RI Series. Industrial standard pin-out No heatsink required SIP4 package High efficiency (80% typ) Capacitor input filter Isolation voltage 1kVdc (min) Voltage; input ±10%, output ±5% UL94V-0 package material
Spec
- Quantity:1set(42pieces)
- Output Voltage : 12V dc
- Input Voltage Range : 21.6 → 26.4 V dc
- Input Voltage Nominal : 24 V dc
- Isolation Voltage : 500V ac
- Power Rating : 2W
- Output Current : 167mA
- Mounting Type : Through Hole
- Number of Outputs : 1
- Package : SIP
- Minimum Temperature : -40°C
- Maximum Temperature : +85°C
- Series : RI
- CODE No.:166-9035
