63-7669-46 ON Semiconductor DF01S, Bridge Rectifier, 1.5A 100V, 4-Pin SDIP DF01S
model:
63-7669-46
brand:
ON Semiconductor
Product Description
Product Model: 63-7669-46Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-7669-46
Product Brand: ON Semiconductor
Features
- UL file E111753 and E326243. Bridge Rectifiers for PCB Surface Mount, DFxxS Series, Fairchild Semiconductor. Glass passivated chip junction Low DC reverse current
Spec
- Quantity:1set(1500pieces)
- Bridge Type : Single Phase
- Peak Average Forward Current : 1.5A
- Peak Reverse Repetitive Voltage : 100V
- Mounting Type : Surface Mount
- Package Type : SDIP
- Pin Count : 4
- Diode Technology : Silicon Junction
- Configuration : Single
- Peak Non-Repetitive Forward Surge Current : 50A
- Maximum Operating Temperature : +150 °C
- Minimum Operating Temperature : -55 °C
- Peak Forward Voltage : 1.1V
- Peak Reverse Current : 5µA
- Length : 8.51mm
- Height : 3.3mm
- CODE No.:166-2576
