Electronic/Electrical Parts and Controll Equipments
63-7471-89 SPNO Reed Relay, 5V dc B05-1A72-B V619
Product Description
Product Model: 63-7471-89Product Brand: Meder Features […]
Contact Us
Product Details
Product Model: 63-7471-89
Product Brand: Meder
Features
- SPNO Reed Relay B Series. Encapsulated in a nickel-plated steel case for magnetic screening Mechanical Life : 10 ;sup>8 ;/sup> Operations Maximum switching current 1A
Spec
- Quantity:1piece
- Contact Configuration : SPNO
- Coil Voltage : 5V dc
- Mounting Type : PCB Mount
- Maximum Switching Voltage AC : 200V ac
- Maximum Switching Voltage DC : 200V dc
- Coil Power : 72mW
- Coil Resistance : 345 Ω
- Length : 31.8mm
- Height : 8.9mm
- Depth : 9.4mm
- Dimensions : 31.8 x 9.4 x 8.9mm
- Isolation Coil To Contact : 2kV dc
- Minimum Operating Temperature : -20°C
- CODE No.:291-9619
