63-7354-21 EPCOS 100nF Polypropylene Capacitor PP 305V ac ±10% Tolerance Through Hole B32922C Series B32922C3104K000
Product Description
Product Model: 63-7354-21Product Brand: EPCOS Features […]
Contact Us
Product Details
Product Model: 63-7354-21
Product Brand: EPCOS
Features
- Capacitors X class are designed for connecting directly across a mains supply, but should NOT be ***d in positions where failure of a capacitor would expose anybody to electric shock. B32921..B32926 Series. EMI suppression capacitors (MKP) X2 class Very small dimensions Self-healing properties Plastic case, epoxy resin sealing (UL 94 V-0) "Across the line" applications
Spec
- Quantity:1bag(1000pieces)
- Capacitance : 100nF
- Voltage : 305V ac
- Mounting Type : Through Hole
- Tolerance : ±10%
- Series : B32922C
- Lead Pitch : 15mm
- Length : 18mm
- Depth : 5mm
- Height : 10.5mm
- Dimensions : 18 x 5 x 10.5mm
- Dielectric : PP
- Terminal Type : Through Hole
- CODE No.:172-5583
