63-7002-84 KEMET 1μF Polypropylene Capacitor PP 310 V ac, 630 V dc ±20% Tolerance Through Hole R46 Series R463N410040N2M
Product Description
Product Model: 63-7002-84Product Brand: KEMET Features […]
Contact Us
Product Details
Product Model: 63-7002-84
Product Brand: KEMET
Features
- EN132400 Class X2, UL1414
- Designed for direct connection to the power distribution system, but cannot be ***d where electrical shock may result from capacitor failure.
- ENEC, UL, cUL, CQC
- KEMET R46 Series
- KEMET R46 Series is a metallized polypropylene film capacitor with self-recovery characteristics.
- Features Rated voltage: 50/60 HzCapacitance range: 0.01 → 10 μFLead spacing: 10.0 → 37.5 mmCapacity tolerance: ± 20%, ± 10% Weatherproof category: 40/110/56, IEC600681 Tape and reel complies with IEC602862 Operating temperature range: -40 → +110 C Factory test for 100% screening @ 2200 V dc/1500 V ac Self-recovery characteristics Applications: X2 Safety classification Required. Can be ***d worldwide for electromagnetic interference (EMI) suppression in direct insertion applications.
- It is int***ed for *** in situations where there is no risk of electric shock even if the capacitor fails. Not suitable for *** with mains type applications.
Spec
- Quantity:1bag(10pieces)
- Capacitance : 1µF
- Voltage : 310 V ac, 630 V dc
- Mounting Type : Through Hole
- Tolerance : ±20%
- Series : R46
- Lead Pitch : 22.5mm
- Suppression Class : X2
- Length : 26.5mm
- Depth : 10mm
- Height : 18.5mm
- Dimensions : 26.5 x 10 x 18.5mm
- Dielectric : Polypropylene
- Terminal Type : Radial
- CODE No.:126-2242
