63-6997-80 Festo Slide Pneumatic Manual Control Valve VBOH Series VBOH-32-G18
Product Description
Product Model: 63-6997-80Product Brand: Festo Features […]
Contact Us
Product Details
Product Model: 63-6997-80
Product Brand: Festo
Features
- VBOH Hand Slide Valve
- The hand slide valve of the Festo VBOH series has a shut-off function for pressurization and exhaust of compressed air systems.
- Features and Benefits: No overlap, so no pressure loss when switching.
- Minimum Installation Effort
- High Flow Rate and Operating Pressure
- Standard Nominal Flow Rate: 236 → 7,691 l/min
- Operating Temperature Range: -10 → +80 °C
- Operating Pressure: -0.95 → +12 bar
- Product Application Information
- Festo's VBOH series hand slide valves can be ***d for air guns and exhaust pneumatic cylinders.
Spec
- Quantity:1piece
- Control Mechanism : Slide
- Connection Port Thread : G 1/8
- Thread Size : 1/8in
- Thread Standard : G
- Manufacturer Series : VBOH
- Maximum Operating Pressure : 12 bar
- Body Material : Aluminium Alloy
- Maximum Flow Rate : 777L/min
- Minimum Operating Temperature : -10°C
- Maximum Operating Temperature : +80°C
- Number of Positions : 3
- CODE No.:125-9900
