63-6996-20 Festo Pneumatic Tee Threaded-to-Tube Adapter NPQP-L-R14-Q8-FD-P10
Product Description
Product Model: 63-6996-20Product Brand: Festo Features […]
Contact Us
Product Details
Product Model: 63-6996-20
Product Brand: Festo
Features
- NPQP Threads-Tube Elbow Push-In Joints
- The Festo NPQP series push-in elbow connectors are designed for easy tube connection and provide a reliable seal. A polypropylene joint for use in applications where the effects of media are severe. Ideal for pneumatic applications with a temperature range of up to 60 °C and a pressure range of up to 10 bar. Features high corrosion resistance (CRC3) and chemical resistance. The NPQP series is an alternative to stainless steel fittings suitable for the food and beverage industry, biotechnology/pharmaceutical, medical technology, clean rooms and process automation.
- Features and Benefits: Quick and easy tube insertion
- Polypropylene housing with stainless steel tube retainer
- Corrosion resistance
- Chemical product resistance
- FDA compliant
- Transparent for easy monitoring
Spec
- Quantity:1bag(10pieces)
- Connection Style : Threaded-to-Tube
- Connector A : R 1/4
- Connector B : Push In 8 mm
- Connector A - Gender : Male
- Body Material : Polypropylene
- Manufacturer Series : NPQP
- Maximum Operating Pressure : 10 bar
- Maximum Operating Temperature : +60°C
- Minimum Operating Temperature : -20°C
- Chemical Resistant : Yes
- CODE No.:125-9684
