63-5095-09 TRACOPOWER TMR 1SM 1W Isolated DC-DC Converter Surface Mount, Voltage in 9 → 18 V dc, Voltage out 5V dc TMR 1-1211SM
Product Description
Product Model: 63-5095-09Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-5095-09
Product Brand: TRACOPOWER
Features
- Traco 1W SIP Fully Regulated Surface Mount DC-DC Converter - TMR 1 SM Series. The Tracopower TMR 1 series is a ultra compact 1W isolated DC-DC converter in SIP package with regulated output voltages. The TMR 1 has a wide 2:1 input voltage range and fully regulated outputs. Wide 2:1 input voltage range Fully regulated outputs Operating temperature -40°C to +85°C No minimum load required I/0 isolation 1500 VDC Short circuit protection Compact SIP package
Spec
- Quantity：1piece
- Output Voltage : 5V dc
- Input Voltage Range : 9 → 18 V dc
- Input Voltage Nominal : 12 V dc
- Isolation Voltage : 1500V dc
- Power Rating : 1W
- Output Current : 200mA
- Mounting Type : Surface Mount
- Number of Outputs : 1
- Efficiency : 80%
- Package : SMD
- Load Regulation : 1%
- Maximum Temperature : +85°C
- Series : TMR 1SM
- CODE No.:781-3128
