63-5080-53 Samtec TSM, 14 Way, 2 Row, Straight Pin Header TSM-107-01-L-DV
Electronic/Electrical Parts and Controll Equipments

63-5080-53 Samtec TSM, 14 Way, 2 Row, Straight Pin Header TSM-107-01-L-DV

model: 63-5080-53
brand: Samtec

Product Description

Product Model: 63-5080-53Product Brand: Samtec Features […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-5080-53
Product Brand: Samtec

Features

  • TSW series PCB through hole board-to-board square post header terminals with a 5.84mm post height mate with the following: BCS standard box sockets - see stock number ; 766-6499 766-6499 typically SSW socket strips - see stock number ; 765-5593 765-5593 typically SSM surface mount socket strips - see stock number ; 765-5357 765-5357 typically Post header terminals with an 8.13mm post height mate with the following: SSM surface mount socket strips (part numbers SSM-xxx-x-DH only) stock number ; 765-5357 765-5357 typically. SMT 2.54mm Square Post Header Terminal Strip - TSM Series. TSM series SMT board-to-board square post header terminal strips with a 2.54mm pitch, a black liquid crystal polymer insulator and phosphor bronze terminals with 0.25μm gold on post and matte tin on tail. These TSM series surface mount PCB board to board square post header terminal strips are available in a variety of configurations including single and double row, straight and right angle body orientation and an option of post lengths. The operating temperature range for these TSM series PCB SMT header terminals is -55 to 125°C. TSM PCB SMT headers with part number TSM-xxx-xx-x-SH are single row with horizontal pins. TSM PCB SMT headers with part number TSM-xxx-xx-x-SV are single row with vertical pins. TSM PCB SMT headers with part number TSM-xxx-xx-x-DH are double row with horizontal pins. TSM PCB SMT headers with part number TSM-xxx-xx-x-DV are double row with vertical pins. TSM PCB SMT headers with part number TSM-xxx-01-x-xx have a 5.84mm post height. TSM PCB SMT headers with part number TSM-xxx-02-x-xx have a 8.13mm post height.

Spec

  • Quantity:1piece
  • Series : TSM
  • Pitch : 2.54mm
  • Number of Contacts : 14
  • Number of Rows : 2
  • Body Orientation : Straight
  • Mating Pin Length : 5.84mm
  • Connector System : Board to Board, Wire to Board
  • Termination Method : Solder
  • Contact Plating : Gold
  • Current Rating : 7A
  • CODE No.:765-6530
