Features

• UL, CSA, VDE, SEMKO for SLE6 and SLE10 switches UL, CSA, VDE, SEMKO for SL10K and SLE10 K switches UL, CSA, VDE, SEMKO for SLE210K switches
• Fujisoku Miniature Power Locker Switches - SL and SLE Series
• The single-pole and two-pole rocker switches of the SL and SLE series by Fujisok are non-illuminated miniature rocker switches with on-off or on-on alternate switching operation.
• This black rocker switch body snaps to a 19.2 x 12.9 mm or 19.4 x 12.9 mm panel cutout with a 0.75→3 mm panel thickness. The securing ribs in the switch housing ensure a secure fixation.
• The SL and SLE rocker switches are available in a variety of terminal types, including light angle mounting, solder tags, and 4.8 x 0.5 mm and 4.8 x 0.8 mm faston/quick connect type tab terminals. For the optimum connector to be engaged, refer to the part number.; 488-1229 488-1229 and; Refer to 488-1241 488-1241.
• Other options in the SL and SLE series include the IP 64 type with dust and water resistance and the high inrush switch. Both types are available with and without the abrasion resistant white mark (Detailed options for terminal types and actuator marks are summarized in the table below.).
• Maximum resistance switch rating: 6 A and 10 A Minimum rating: 10 mA @ 5 V ac/dc Minimum contact distance: 3 mm for the SLE6, SLE10, and SL10K switches Dust-proof for the SLE6, SLE10, and SLE210K switches IP 64 grade protection against dust and water ingress The SL10K and SLE210K switches support rated inrush currents up to 100 A (induction) Electrical life: 10,000 times for the SLE6, SLE10, and SLE210K switches, 10 20,000 times for the SL10K and SLE10K switches Maximum contact resistance: 20 MΩ Insulation strength: 1500 V ac, 1 minute Minimum insulation resistance: 100 MΩ Operating temperature range: -25→+85°C
