Features

• A1126 Chopper Stabilised Omnipolar Hall Effect Sensor Switches, Allegro Microsystems. The Allegro Microsystems A1126 is an omnipolar, ultrasensitive Hall-effect switch with a digital output. They include a voltage regulator, Hall-voltage generator, small-signal amplifier, chopper stabilisation, Schmitt trigger, and a short circuit protected open-drain output. This device has an integrated regulator permitting operation to 24 V. They are suitable for operation through ext***ed temperature ranges from -40°C to 150°C. Activation the A1126 with either a north or a south polarity and without a magnetic field, the output is off. This magnetic polarity indep***ence makes it an excellent replacement for reed switches. It also simplifies manufacturing as it does not require the magnets to be orientated. The A1126 is rated for operation between the ambient temperatures –40°C to 150°C. AEC-Q100 automotive qualified Omnipolar operation High speed, 4-phase chopper stabilisation Low switchpoint drift Superior temperature stability Insensitive to physical stress Reverse-battery protection Robust EMC capability Robust ESD
