63-5051-78 Vishay IHLP Series Type 2225 (5664M) Shielded Wire-wound SMD Inductor with a Metal Composite Core, 6.8 μH ±20% IHLP2525CZER6R8M01
Product Description
Product Model: 63-5051-78Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-5051-78
Product Brand: Vishay
Features
- IHLP2525CZ-01 Series Magnetically Shielded Wire Wound Chokes. Vishay IHLP-2525CZ-01 series high current low profile shielded inductors. The IHLP-2525CZ-01 series handles high transient current spikes without saturation and has ultra low buzz noise due to its composite construction. Frequency range up to 5.0 MHz Lowest DC Resistance / μH, in this package size. Applications include: PDA/****book/desktop/server devices; High current POL converters; Low profile, high current power supplies; Battery powered devices; DC/DC converters in distributed power systems; DC/DC converter for Field Programmable Gate Array (FPGA)
Spec
- Quantity：1bag(5pieces)
- Inductance : 6.8 μH
- Maximum DC Current : 4.5A
- Package/Case : 2225 (5664M)
- Length : 6.86mm
- Depth : 6.47mm
- Height : 3mm
- Dimensions : 6.86 x 6.47 x 3mm
- Shielded : Yes
- Tolerance : ±20%
- Maximum DC Resistance : 60mΩ
- Series : IHLP
- Core Material : Metal Composite
- Maximum Self Resonant Frequency : 5MHz
- Minimum Operating Temperature : -55°C
- CODE No.:748-7101
