62-8556-79 Diaphragm Precision Micro Injection Pump Smooth Flow Pump Q Series TK-7
Product Description
Product Model: 62-8556-79Product Brand: Biomachinery Fe […]
Contact Us
Product Details
Product Model: 62-8556-79
Product Brand: Biomachinery
Features
- A high-performance anesthetic that can be ***d for mice to 50 kg animals.
- Stable concentration is maintained from a low flow rate of 0.25 L/min, and there is no drift of anesthetic concentration due to ambient temperature.
- Since the upper precision valve is adopted, there is no deviation of flow rate due to pressure loss, and accurate flow rate is guaranteed.
- It is very convenient to switch between induction and maintenance anesthesia with a 2-way valve with one touch.
- Since the pump discharge pressure is high, it is possible to anesthetize long and thin tubes longer than 5 m, and to anesthetize many animals (5~10 animals) at once.
- Oxygen flow meter can also be installed. (Sold separately)
Spec
- Model number: QI-100-TT-P-S
- Wetted Part Material:
- Pump Head: PTFE
- diaphragms: PTFE
- Sheet Valve/Packing: Special Fluororubber
- fittings: PTFE
- Maximum Discharge: 100 mL/min
- Maximum discharge pressure: 0.3 MPa
- Flow Setting Range: 0.1~100 mL/min
- Control system: manual operation, calibration, analog input proportional operation, pulse input operation
- Transfer liquid temperature: 0~40°C (without freezing)
- Viscosity of transfer liquid: 200 mPa · s or less
- Connection: φ4 x φ6 Hose
- Size: 110 x 191 x 128.1 mm
- Weight: 1.7 kg
- Power Supply: Single Phase 100~240 V ±10% (Cord Length: 2 m)
- Environmental Resistance: IEC Standard IP65 Equivalent (Dustproof/Waterproof)
- Country of production: Japan
