Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature point: number of revolutions
• Amplitude: 30 mm (reciprocating shaking)
• Shaking speed: 20 ~ 160 rpm (continuously variable)
• Number of shaker racks: 120 test tubes of 10 mm diameter
• Shaking table dimensions: 174 x 180 x 130 mm
• Water tank material: stainless steel (SUS 304)
• Weight: 21 kg
• Power supply: 100 VAC 50/60 Hz 100 W
• Power cord length: 2.5 m, 3 P plug with ground pin (with 3 P -2 P conversion adapter)
• Accessories: Shaking rack (SUS 304)
• External dimensions: 325 x 455 x 285 mm
• Tank capacity: 230 x 390 x 150 mm (13 L)
• *The water tank is detachable.
• Local validation services (IQ/OQ) are also available.　Please contact us.
• *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
• *If you would like to request a local IQOQ, please contact us separately. We need your installation address for the estimate.
