Electronic/Electrical Parts and Controll Equipments
63-4829-67 Metal Film Resistor MFS 1/4 Series 5.6 kΩ 0.25 W ± 1% MFS14CC5601F
Product Description
Product Model: 63-4829-67Product Brand: KOA Features UL […]
Contact Us
Product Details
Product Model: 63-4829-67
Product Brand: KOA
Features
- UL1676 c-UL (CAS-C22.2 No. 1-M94) (File No. E159326) (RK only) AEC-Q200 Certified Metal Film Resistors, 0.25 W, 1% (1/8 W Type), MFS1/4C Series
- KOA MF Series are axially terminated precision resistors.
- This series offers a variety of resistance values.
- The MF through-hole resistor with lead-free termination is ideal for *** in automatic mounting machines.
- The MFS type has twice the power rating of the standard body type.
- The MF1/4, MFS1/4, and MFS1/2 types are AEC-Q200 certified and suitable for automotive applications.
Spec
- Quantity: 1 bag (20 pieces)
- Resistance: 5.6 kΩ
- Rating Power: 0.25 W
- Tolerance: ± 1%
- Technology: Metal Coating
- case styles: formal
- Temperature Coefficient: ± 50 ppm/deg.
- *** styles: axial
- Dimensions : 1.7 (Dia.) x 3.4 mm
- Length: 3.4 mm
- Diameter: 1.7 mm
- Minimum temperature coefficient: -50 ppm/deg.
- RoHS Compliance Status: Compliance
- Securities Code: 491 -1588
