2-2758-01 Portable Torque Driver HF-TD100NC
model:
2-2758-01
category:
toner
Product Description
Product Model: 2-2758-01 Features It is possible to mea […]
Contact Us
Product Details
Product Model: 2-2758-01
Features
- It is possible to measure the tightening force and loosening force of screws and the operating torque.
- It is possible to set the mode such as standard peak/round trip measurement/round trip right rotation peak/round trip left rotation peak.
- Upper and lower tolerances can be set by the comparator function, and OK/NG judgment is possible.
- The battery can be ***d continuously for 10 hours.
Spec
- Model number: HF-TD100NC
- Maximum torque capacity (N･cm): 100
- Resolution (N・cm): 0.01
- Accuracy: +/- 1%
- Memory: 256 times (512 data)
- Auto power OFF: 1 - 99 minutes
- Power supply: AC100 - 240V 50/60Hz output DC12V AC adapter (included)
- Grip size: φ28 x 100mm
- Weight: Approx 800g
