65-3720-03 Friction and Wear Testing Equipment EFM-3 Series EFM-3-H
Product Description
Product Model: 65-3720-03Product Brand: A&D Feature […]
Contact Us
Product Details
Product Model: 65-3720-03
Product Brand: A&D
Features
- Can be ***d for the scientific elucidation and technical evaluation of the properties of sliding friction, lubrication and wear, which is the surface behavior of two materials relative to each other.
- Compliance with JIS K 7218 (Compatible with ring, disc and pin specimens)
- Sliding speed range 0.001~1000 cm/sec
- Friction force measuring range 0.02~10 N m
- Development into a customizable system (e.g., adding measurement and control items)
- [Application]
- Evaluation of friction properties for various materials and products (Metals, plastics, ceramics, bearing materials, brake linings, clutch plates, self-lubricating materials, lubricating oils, etc.)
- measurement of the dynamic friction coefficient
- measurement of wear
- Measurement of critical PV values
- Evaluation of Baking Conditions
- Evaluation of Friction Properties by Combining Various Materials
- Evaluation of the relationship between surface treatment and friction characteristics
- Evaluation of the relationship between environmental conditions and friction characteristics
Spec
- Application: Durable Type
- Pressure load range: 20~5000
- Maximum rotational shaft torque (N · m): 3
- Friction force range (N · m): 0.02~3
- Shaft speed (rpm): MAX3350
- Slip speed range (cm/sec): 0.6~400 when using standard ring specimens
- Maximum continuous operation time (hr): 1000
- Drive motor: AC servomotor
- Adaptive specimens: rings, discs, pins
- Operation: Color Touch Panel
- Display: Pressure detection value, friction force, rotation speed, pseudo wear amount, test time, manual operation command button, rotation/stop
- Temperature indicator: For test specimens, temperature indicator 0~300°C, compatible with K thermocouple (sheath diameter Φ1 mm)
- Automatic pressurization mechanism: yes
- Automatic operation *** setting and operation: Operation time, automatic test stopped after decompression work according to various limit conditions
- Automatic stop (no abnormal stop or decompression work at the time of stop): motor abnormality, pressure full scale over, friction force full scale over, pressure movement upper and lower limit
- Load Detector: Load Cell Type 5 kN (for Pressurization)/1 kN (for Pressurization)/100 N (for Pressurization/Friction)/20 N (for Friction)
- Pressure Spring: 3 Types for 5 kN, 1 kN, and 100 N
- Power (Cable length 5 m, Cable diameter Φ3): 200 VAC, 6kVA
- Ground fault breaker: included
- Body Dimensions: W630 x D660 x H1600mm
- Body mass: 350 kg
