7-3895-01 Pressure Drainage Pump SANISPEED SSPPLUS-100
model:
7-3895-01
category:
gasmonitors
Product Description
Product Model: 7-3895-01 Features The VP20 and VP25 thi […]
Contact Us
Product Details
Product Model: 7-3895-01
Features
- The VP20 and VP25 thin drains can pump up to 70 m horizontal and 6 m head.
- It can be installed even in the field where there is no main drain on the primary side or the drainage gradient cannot be secured.
- Since there are 4 inlets, it is also possible to drain multiple water distribution equipment.
- * Please handle the installation work by yourself.
Spec
- Model number: SSP -100
- Width x Depth x Height: 185 x 415 x 330mm
- Inlet/discharge pipe diameter: Inlet: 40 A x 4, Discharge: 20 to 25 A x 1
- start-up water level : installation surface + 120 (± 10) mm (start-up at about 3 L inflow)
- Power supply: AC100V 50/60 Hz 380/460 W
- Heatproof temperature: 75 ℃ (No continuous inflow for 5 minutes or more)
- Weight: 5.8 kg
