63-4698-73 ITW Single Pole Double Throw (SPDT) Momentary Push Button Switch, 16 (Dia.)mm, Panel Mount 49-59221
Product Description
Product Model: 63-4698-73Product Brand: ITW Features Hi […]
Contact Us
Product Details
Product Model: 63-4698-73
Product Brand: ITW
Features
- High Current Sealed Pushbuttons. The 49-59 series offers a wide selection of options suitable for *** in a wide variety of applications. They are panel sealed to IP67 making them ideal for harsh environments. They have a wide selection of colours, illuminated or non-illuminated options and tabs or insulated leads. They are all panel mounted through a 16mm panel cut out. Panel mount pushbuttons with rear mounted microswitches that snap into place from the rear after assembly of the actuator UL94V-Ø rated body and button Form Z (1 N/O + 1 N/C) contact Panel sealed to IP67 Max.Panel thickness 1.5 mm
Spec
- Quantity：1piece
- Switch Operation : Momentary
- Mounting Type : Panel Mount
- Contact Configuration : Single Pole Double Throw (SPDT)
- Panel Cut Out Size : 16 (Dia.)mm
- Panel Cut Out Diameter : 16mm
- Actuator Colour : Black
- Contact Current Rating : 10 A @ 250 V ac
- Actuator Shape : Dome
- Terminal Type : Solder
- Actuator Type : Button
- CODE No.:157-3666
