Spec

• convection formula: Radiation
• Operating temperature range (°C): 50 °C to 200 °C
• Temperature adjustment precision (°C): ± 1 °C at 200 °C
• Temperature rise time: about 120 minutes, from R.T. to 200 °C
• Vacuum operating range: 100 kPa to 0.13 kP (a vacuum standard)
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Microcomputer PID Control (TC-SVI System)
• Operation type: Standard Operation, Program Operation (maximum 100 steps) 1 minute, to 99 hours 59 minutes
• Temperature sensor: K class thermocouple
• Heater: Band heater
• Heater capacity (kW): 3.3 kW
• Vacuum Gauge: Bourdon Tube Type (0 kPa, to, -100, kPa)
• Interior: SUS304
• Door Packing: Silicone Rubber
• Safety device: Self-diagnostic function (Overheating, temperature sensor error, heater disconnection, SSR short circuit, ambient temperature error), indep***ent overheat prevention device, control circuit protection f***, key lock function, overcurrent/leakage breaker
• inner dimension [Effective Dimensions]: W 600 mm x D 600 mm x H 600 mm [H 567 mm]
• external dimensions ( mm ) : W 850 mm x D 855 mm x H 1,125 mm
• Internal volume (approx. L): approx. 216 L
• Observation Window: W 350 mm x H 350 mm tempered glass t 15 mm
• number of shelves/pitch: 6 stages/90 mm (Fixed Shelf Support)
• Vacuum Mouth: outer diameter 22 mm x L 40 mm (brass)
• Purge Port: Rc 3/8 (brass)
• power supply (50Hz/60Hz): 200 VAC Single-phase 16.5 A
• Required power supply Equipment: 200 VAC Single-Phase 30 A
• Mass (approx. kg): approx. 290 kg
• Accessories: shelf board 2 pieces, Rubber Elbow 1 piece, Fixed metal bracket 4 pieces (Mounting Screw 8 pieces)
