64-0828-52 Oxygen Densitometer TA470JS
Product Description
Product Model: 64-0828-52Product Brand: ICHINEN TASCO C […]
Contact Us
Product Details
Product Model: 64-0828-52
Product Brand: ICHINEN TASCO CO., LTD.
Features
- It can be ***d in a wide range of ways, from checking oxygen concentration to alarms.
- High-Performance Oxygen Concentrator (with Alarm) Equipped with Long-Life Sensor
- Barometric Pressure Correction Function, Maintenance Notification Timer, Auto Adjustment Function First in the Industry
- Battery and External Power Supply Can Be Used in Parallel.
Spec
- Detected gas: oxygen
- Detection principle: Galvani battery type
- Measurement Range: 0.0 to 100.0%
- resolution: 0.001
- Measurement accuracy: ± 0.5% (0.0 to 25.0%) ± 3.0% (25.1% or more)
- Operating temperature range: -10 to + 40 °C
- Operating humidity range: 5 to 95 %RH (non-condensing)
- Operating pressure range: 811 to 1100 [hPa]
- Response speed: T 90 within 20 seconds (20.9 → 100.0%), (20.9 → 10.5%)
- Warning delay: within 5 seconds (20.9 → 18.0%, 10 to 11% oxygen exposure)
- standards: Low Voltage Directive, RoHS Directive JIS T 8201 In-ho*** Testing Completed
- Alarm density setting value: 2 points can be arbitrarily set (initial value ALM1: 19.5% ALM2: 18.0%)
- Alarm function: Electronic buzzer (80 dB), red LED 2 pieces flashing
- alarm output: relay non-voltage 1c contact
- Maximum allowable range: 30 VDC 1 A MAX
- *1 The sensor life is not guaranteed.
- *2 Can be changed to current output (4 -20 mA) by option (*** of model -AA)
