64-0826-90 High-Precision Radiation Thermometer TA410S
Product Description
Product Model: 64-0826-90Product Brand: ICHINEN TASCO C […]
Contact Us
Product Details
Product Model: 64-0826-90
Product Brand: ICHINEN TASCO CO., LTD.
Features
- Easy Measurement from Point to Surface
- Measuring micro surface of φ2.5 mm such as IC substrate.
- Small object measurement at hand.
- The LED accurately indicates the measured part. *Handy spot measuring radiation thermometer is Tasco's original product.
Spec
- measurement temperature range: -50 to + 500 °C
- Wavelength: 8, to 14, μm.
- measurement temperature range: -50 to + 500 °C
- Display resolution: 0.0 to + 199.9 °C/0.1 °C, other ranges/1 °C
- Measurement accuracy: within -50 to 0 °C/± (5% of absolute value of reading + 1.5) °C, 0.0 to + 199.9 °C/± 1 °C + 200 to + 500 °C/± (0.5% of reading + 0.5) °C
- Response speed: within 0.8 sec. (95% response)
- Emissivity setting: 0.10 to 1.00 (0.01 steps)
- aiming: LED spot markers
- Operating temperature and humidity range: Temperature/0 to + 50 °C, Humidity/35 to 85% non-condensing
- power supply: AAA size, battery, 4 pieces
- Size: 170 x 40 x 36 mm
- Mass: 140 g (including battery)
- Function: upper and lower Limit Warning (Setting Range: -50 to + 505)/Instantaneous/MAX/MIN/Hold/Auto Power Off (15 seconds)/Continuous Measurement
- Standard Accessories: AAA size, battery, 4 pieces, Operation Manual, Carrying Case
